Real Time Power Data Solutions

mini RTU with IEC 101 Protocol

Remote Terminal Unit(RTU) for providing real time power data to Load Dispatch Center. It interfaces with IEC 60870-5-101 [IEC101] SCADA system. It provides Analog Parameters like MW, MVAR, Voltage and Frequency and Status points of Circuit breaker, Isolator, Sequence of Events(SOE) to Control Station. It supports upto 10 Bays of a Sub-Station.

IEC 60870-5-101 [IEC101] is a standard for power system monitoring, control & associated communications for telecontrol, teleprotection, and associated telecommunications for electric power systems.

mini RTU with IEC 104 Protocol

Remote Terminal Unit(RTU) for providing real time power data to Load Dispatch Center. It interfaces with IEC 60870-5-104 [IEC104] SCADA system. It provides Analog Parameters like MW, MVAR, Voltage and Frequency and Status points of Circuit breaker, Isolator, Sequence of Events(SOE) to Control Station. It supports upto 10 Bays of a Sub-Station.

IEC 60870-5-104 (IEC 104) protocol is an extension of IEC 101 protocol with the changes in transport, network, link & physical layer services to suit the complete network access. The standard uses an open TCP/IP interface to network to have connectivity

mini RTU with WAN Interface

mini Remote Terminal Unit(RTU) for extending upto 4 Analog parameters to Remote RTU Station. It provides Analog Parameters like MW, MVAR, Voltage and Frequency to the Nearest available Sub-Station RTU over Radio Link or GSM based on Radio Feasibility Survey.

mini RTU with Modbus Protocol

Remote Terminal Unit(RTU) for providing real time power data to Control Center. It interfaces with SCADA system. It provides Analog Parameters like MW, MVAR, Voltage and Frequency and Status points of Circuit breaker, Isolator, Sequence of Events(SOE) to Control Station. It supports upto 10 Bays of a Sub-Station.

Modbus is a serial communications protocol. Simple and robust, it has since become a de facto standard communication protocol, and it is now a commonly available means of connecting industrial electronic devices.
